Description
The Winson WNI-6750g is a 2D CMOS wired handheld barcode scanner designed for fast, accurate, and reliable barcode scanning. With an advanced area imaging CMOS sensor and scanning speeds of up to 60 FPS, it can efficiently capture both 1D and 2D barcodes, including QR Code, PDF417, DataMatrix, and other commonly used barcode formats.
The scanner supports a scanning distance of up to 550mm and features a wide scanning angle of 46° horizontal and 38° vertical, making barcode reading convenient in different working positions. Its high-precision scanning capability also allows it to read low-contrast and small barcodes.
For flexible connectivity, the WNI-6750g supports USB HID/COM and RS-232 interfaces. It also features Auto Scan/Hands-Free Mode, bright white LED illumination, and a red target pointer for accurate barcode positioning.
Built for everyday business use, the scanner features 1.5m drop resistance and an IP54-rated design for protection against dust and splashes. Weighing only 120g, it is lightweight and comfortable for extended use.
The Winson WNI-6750g is suitable for retail shops, POS systems, supermarkets, inventory management, and other commercial applications.
| Specification | Details |
|---|---|
| Brand | Winson |
| Model | WNI-6750g |
| Type | 1D/2D Wired Barcode Scanner |
| Sensor | CMOS Area Imaging Sensor |
| Resolution | 752 × 480 Pixels |
| Interface | USB (HID & COM Emulation) |
| Scanning Speed | Up to 60 FPS |
| Barcode Support | 1D & 2D Barcodes |
| Minimum Code Thickness | 1D: 3 mil (0.076 mm), 2D: 5 mil (0.127 mm) |
| Minimum Code Contrast | 15% |
| Scanning Range | Up to 550 mm |
| Scanning Angle | Horizontal: 46°, Vertical: 38° |
| Illumination | White LED + Red Target Indicator |
| Reading Indication | Sound & Light |
| Auto Scanning | Yes (Hands-Free) |
| Supported 2D Codes | QR Code, PDF417, DataMatrix, etc. |
| Special Code Support | Honest Sign Codes |
| EVOTOR Compatibility | Yes |
| Protection Class | IP54 |
| Impact Resistance | Withstands 1.5m drops onto concrete |
Warranty Information
| Warranty | Details |
|---|---|
| Warranty | 1 Year |
